| MODEL | LEJ-640 | ||
| Printing method | Piezoelectric inkjet / Grit roller feed | ||
| Acceptable media | Width | Roll media: 8.3 to 64 in. (210 to 1625 mm) / Rigid or cut sheet: 9.9 to 64 in. (250 to 1625 mm) | |
| Thickness | Roll media: Maximum 39 mil (1.0 mm) with liner / Rigid or cut sheet: 0.51 in. (13 mm) | ||
| Weight | Roll media: Maximum 88 lb. (40 kg) / Rigid or cut sheet: Maximum 26 lb. (12 kg) | ||
| Roll outer diameter | Maximum 8.3 in. (210 mm) | ||
| Core diameter | 3 in (76.2mm)
2 in (50.8mm) [requires optional flanges] | ||
| Media take-up system | Maximum 8.3 in (210 mm) outer diameter / Maximum 88 lb. (40 kg) weight | ||
| Printing width | Maximum 63.6 in (1615 mm) | ||
| Maximum Printing Speed | 133 sqft./hr. in CMYK mode | ||
| Ink Cartridges | Type | 10.2 to 63.6 in. (259 to 1615 mm) ECO-UV inks | |
| Capacity | 220 ml (± 5 ml) | ||
| Colors | 6 colors (Cyan, Magenta, Yellow, Black, White and Gloss) | ||
| Configuration | CMYK+Gloss+White, CMYK+White+White or CMYK+Gloss+Gloss | ||
| Ink curing unit | Dual UV LED Lamps | ||
| Printing resolutions | 360×720 dpi, 720×1080 dpi, 720×1440 dpi, 1440×1440 dpi | ||
| Distance accuracy | Error of less than ± 0.3 % of distance traveled, or ± 0.012 in (0.3 mm), whichever is greater. | ||
| Interface | Ethernet (10 BASE-T / 100 BASE-TX, automatic switching) | ||
| Power-saving feature | Automatic sleep feature | ||
| Power supply | Voltage and frequency | AC 100 to 240 V ± 10%, 50/60 Hz | |
| Required power capacity | Maximum 5.7 A | ||
| Power Consumption | During operation | Maximum 500W | |
| Standby mode | Approx. 15.2 W | ||
Dimensions
(with stand) | Without table unit : 126[W]x33[D]x51[H] in (3184[W]x836[D]x1281[H] mm) / With table unit: 126[W]x145[D]x51[H] in (3184[W]x3658[D]x1281[H] mm) | ||
| Weight (with stand) | Without table unit: 530 lb. (240 kg) / With table unit: 697 lb. (316 kg) | ||
